Vela S
The luminaire presented here is a modern streetlight characterized
by a minimalist and dynamic design.
Its key distinguishing feature is a striking, openwork arm
with a streamlined shape,
which lends the entire structure a sense of lightness
and a futuristic character.
The lamp head itself, with its geometric, slightly tapered profile,
houses an advanced LED module with precision optics that
ensure efficient and uniform light distribution.
Download Files:
Applications: Street and urban lighting.
Tilt angle: 0°
Weight: 16.53 Lbs / 7.5 kg
EPA: Side: 0.65 ft2 (0.06m2)
Top: 1.51 ft2 (0.14m2)
(Cross Section Surface)
Use Drag coefficient factor - 0.5
Mounting: M2B - 2 3/8” x 4” L
Power Factor: >0.9 (full load)
Power cable: 12GA
Connector-IP68: Cable Dia. 0.27”-0.39”
(7mm-10mm)
Optical unit lifetime
(Ta: 77°F/25°C)
525mA: L90B10 ≥ 100 000 h
(Including critical failures)
L90 > 100 000 h, TM-21
700mA: L90B10 ≥ 100 000 h
(Including critical failures)
L90 > 100 000 h, TM-21
